GoodWe ESA Battery Module 5 kWh - GW5.1-BAT-D-G20
GoodWe ESA 5 kWh battery module – GW5.1-BAT-D-G20
The GoodWe ESA 5 kWh battery module is the modular storage unit of the powerful GoodWe ESA all-in-one energy storage solution. The system combines a three-phase hybrid inverter with modern high-voltage battery technology and enables particularly efficient use of the generated solar energy.

Product features
Modular storage system
5 kWh storage capacity per battery module
High scalability
Flexible storage capacities from 5 kWh up to 108 kWh
All-in-one system solution
Optimally matched to the GoodWe ESA hybrid energy storage systems
Ideal for residential & small C&I
Suitable for detached houses and smaller commercial applications
Thanks to the modular design, the storage capacity can be flexibly adapted to individual energy needs. The GoodWe ESA series supports storage capacities from 5 kWh up to 108 kWh and is therefore suitable for both detached houses and smaller commercial applications. An integrated DC-DC converter in each battery module optimises energy management and enables flexible expansion of the storage system.
In conjunction with the ESA system solution, users benefit from fast backup switchover within ≤ 4 ms, up to 200% PV oversizing and a system efficiency of up to 98% thanks to modern SiC technology. A multi-level safety architecture, standard battery module heating and integrated fire protection ensure reliable operation under demanding conditions.
Whether for self-consumption optimisation, backup supply or a flexibly scalable PV storage solution, the GoodWe ESA 5 kWh battery module forms the modular basis for an intelligent and future-proof energy system.
Features at a glance
- Modular storage system: 5 kWh storage capacity per battery module
- High scalability: flexible storage capacities from 5 kWh up to 108 kWh
- All-in-one system solution: optimally matched to the GoodWe ESA hybrid energy storage systems
- Ideal for residential & small C&I: suitable for detached houses and smaller commercial applications
- Integrated DC-DC converter: intelligent energy optimisation at module level
- Fast backup switchover: backup operation with a switchover time of ≤ 4 ms
- High PV utilisation: simultaneous charging of the battery and supply of loads
- Up to 200% PV oversizing: high PV input power for maximum energy yields
Technical data
| Manufacturer | GoodWe |
|---|---|
| Modular storage system | 5 kWh storage capacity per battery module |
| High scalability | Flexible storage capacities from 5 kWh up to 108 kWh |
| All-in-one system solution | Optimally matched to the GoodWe ESA hybrid energy storage systems |
| Ideal for residential & small C&I | Suitable for detached houses and smaller commercial applications |
| Integrated DC-DC converter | Intelligent energy optimisation at module level |
| Fast backup switchover | Backup operation with a switchover time of ≤ 4 ms |
| High PV utilisation | Simultaneous charging of the battery and supply of loads |
| Up to 200% PV oversizing | High PV input power for maximum energy yields |
| Quiet system operation | Noise level from < 35 dB |
| Multi-level safety concept | Six-layer safety architecture with cell monitoring and fire protection |
| Integrated fire protection | Aerosol fire suppressant as standard in the battery module |
| Winter-proof | Integrated battery module heating for reliable operation at low temperatures |
| 10-year warranty | Manufacturer's warranty on inverter and battery |
| Storage capacity per battery module | 5 kWh |
| System capacity | 5–108 kWh |
| Max. number of battery modules | Up to 12 battery modules with two battery towers |
| Battery technology | High-voltage battery system |
| Module technology | Integrated DC-DC converter in each battery module |
| Compatible system | GoodWe ESA all-in-one energy storage system |
| Inverter power range | Three-phase 5–30 kW |
| MPPT configuration 5–8 kW | 3 MPPT / 3 Strings |
| MPPT configuration 10–20 kW | 4 MPPT / 4 Strings |
| MPPT configuration 25–30 kW | 4 MPPT / 6 Strings |
| Max. input current per string | 21 A |
| PV oversizing | Up to 200% |
| Backup switchover time | ≤ 4 ms |
| Off-grid continuous power | Up to 110% |
| Off-grid peak power | Up to 200% for 10 seconds |
| Backup connection | Integrated |
| Smart Meter | Integrated |
| Parallel connection | Up to 6 inverters |
| Max. battery storage capacity in parallel operation | Up to 576 kWh |
| Fire protection | Integrated aerosol fire suppressant in the battery module |
| Communication | WLAN / LAN / Bluetooth / RS485 |
| Monitoring | GoodWe SEMS+ platform |
| AFCI | Integrated |
| AC surge protection | Type 2 integrated |
| DC surge protection | Type 2 integrated |
| Warranty | 10 years |
Subject to changes and errors, images similar.
