BYD HVB Battery Extension – 2.97 kWh
BYD Battery-Box HVB 2.97 kWh battery extension
The BYD Battery-Box HVB 2.97 kWh battery module is the basic unit of the modular BYD Battery-Box HVB high-voltage storage series. With modern lithium iron phosphate technology (LiFePO₄) the module offers high safety, a long service life and reliable performance for private and commercial energy storage solutions.
15-year manufacturer's warranty



Thanks to the innovative, cable-free stacking concept, the battery module can be installed quickly and easily. Several HVB modules can be combined into a powerful high-voltage storage system and flexibly adapted to individual energy requirements.
The compact design, high energy density and proven BYD storage technology make the HVB battery module the ideal solution for self-consumption optimisation, backup applications and modern photovoltaic systems.
Compatibility note:
The BYD Battery-Box HVB batteries are compatible with hybrid inverters from leading manufacturers such as Kostal, Fronius, GoodWe, SMA und Solis . The current compatibility list for HVB can be found in the "Downloads" section of this product page.
Product benefits
BYD Blade battery technology
The BYD Blade battery technology in combination with the innovative cell-to-pack (CTP) structure ensures maximum safety and stability. The well-thought-out battery design offers a high level of protection against thermal influences and ensures reliable operation throughout the service life of the battery.
Easy installation and flexible expansion
With only 27.3 kg weight per 2.97 kWh battery module the BYD Battery-Box HVB allows easy handling, fast installation and flexible expansion of the storage system. The compact design facilitates transport, installation and later system expansions.
Long-term investment security
The BYD Battery-Box HVB series impresses with the highest quality and longevity. Thanks to the 15-year manufacturer's warranty you benefit from long-term investment security and a reliable energy storage system for many years.
Features at a glance
- • Model designation: BYD Battery-Box HVB battery module
- • Battery cell type: lithium iron phosphate (LiFePO₄, cobalt-free)
- • Usable capacity: 2.97 kWh
- • Number of battery modules: 1 module (only in combination with BCU and further HVB modules)
- • Nominal voltage: 51.2 V
- • Operating voltage: 40–57.6 V DC
- • Max. charge/discharge current: 50 A
- • Peak current: 98 A (15 seconds)
Technical data
| Manufacturer | BYD |
|---|---|
| • Model designation | BYD Battery-Box HVB battery module |
| • Battery cell type | Lithium iron phosphate (LiFePO₄, cobalt-free) |
| • Usable capacity | 2,97 kWh |
| • Number of battery modules | 1 module (only in combination with BCU and further HVB modules) |
| • Rated voltage | 51,2 V |
| • Operating voltage | 40–57,6 V DC |
| • Max. charge/discharge current | 50 A |
| • Peak current | 98 A (15 seconds) |
| • Depth of discharge (DoD) | 95 % |
| • Communication | Via BCU (CAN / RS485) |
| • Protective functions | Overvoltage/undervoltage protection, overcurrent protection and temperature monitoring |
| • Weight | 27,3 kg |
| • Area of application | Indoor and outdoor |
| • Operating temperature | −20 °C to +50 °C |
| • Humidity | 5–95% (non-condensing) |
| • Protection rating | IP55 (in the overall system) |
| • Cooling | Natural convection (passive) |
| • Mounting type | Part of the tower structure, floor mounting required |
| • Scalability | Up to 10 modules per system (29.6 kWh), up to 3 systems in parallel (89.07 kWh) |
| • Warranty | 15-year manufacturer's warranty |
Subject to changes and errors, images similar.
