SMA Sunny Tripower 5.0 Smart Energy 5kW Hybrid Inverter STP5.0-3SE-40

SMA Sunny Tripower 5.0 Smart Energy 5kW Hybrid Inverter STP5.0-3SE-40

The SMA Sunny Tripower Smart Energy is a hybrid inverter that intelligently connects to the SMA energy management system. With a Sunny Home Manager 2.0, heat pumps and e-charging stations can be integrated in addition to the battery. Forecast-based charging increases the efficiency of the overall system and charges the battery during lunchtime.

product advantages

• Compatible with SMA Sunny Home Manager 2.0
• Integrated switching device for emergency power
• Compatible with SMA Energy App, 360° App and Sunny Portal
• Also stores the energy from additional PV inverters or a CHP plant
• AC and DC ÜSS Type 2 integrated

Product features SMA Hybrid STP 5.0 SE

• Mains connection: 3-phase
• AC rated power: 5 kVA
• Max. power in emergency power mode: 10 kVA (max.10 s)
• MPP tracker: 2
• String connections per MPPT: 1
• Communication: WLAN, Ethernet, CAN
• Incl. 3 m battery cable with MC4 connectors
• Typical noise emissions: 30 dB (A)
• Protection class: IP 65
• Dimensions: 598 x 500 x 173 mm (H x W x D)
• Weight: 30.0 kg
• Warranty: 5 years + 5 years
