SUNGROW SBR096 BATTERY STORAGE 9.6KWH

SUNGROW SBR096 HIGH VOLTAGE LITHIUM IRON PHOSPHATE BATTERY 9.6 KWH

The Sungrow SBR battery storage starts with 3 modules, but the storage can be expanded to up to 8 modules. The output can be expanded modularly from 9.6 kWh to up to 25.6 kWh. Up to 4 units can be operated in parallel in a capacity range of 9-100 kWh. This makes the system very flexible. Thanks to the low weight of only 33 kg per module and the slim design, the storage can be installed by one person using plug and play.

The Sungrow 3-phase hybrid inverter detects the battery storage after installation and automatically integrates it into the system. The optimally coordinated emergency power system with state-of-the-art load control and a switching time of less than 20 ms offers maximum reliability.

BENEFITS OF THE PRODUCT

• Permanent 30 A charging and discharging current possible
• Expandable from 3 to up to 8 modules per unit over the entire service life
• Up to 4 units can be connected in parallel for a capacity range between 9-100 kWh
• Certified multi-stage protection concept including VDE 2510-50
• Due to low weight and compact design, installation by only 1 person possible
• Plug and Play between the individual battery modules
• Powerful emergency/backup power and off-grid functionality
• 10-year product warranty

PRODUCT FEATURES SUNGROW SBR096 STORAGE TANK WITH 9.6 KWH

• Battery capacity: 9.6 kWh
• Nominal voltage: 192 V
• Max. output current: 30 A
• Peak output current: 42 A for 10 seconds
• Weight: 114 kg
• Protection class: IP55
• Dimensions: 625 x 545 x 330 mm
